Technical parameters
1.High-voltage generator, tube (X-Ray Tube Assembly)
| Component parameter name |
Parameter |
| Nominal output electrical power |
5.0 kW |
| Maximum output electrical power |
5.0 kW |
| Anode type |
Fixed bifocal anode |
| The size of the focal spot |
Small focus 0.6 mm, large focus 1.2 mm |
| Anode heat capacity |
60 kJ (80 kWh) |
| Continuous anode input power |
560W (maximum duration: 10 minutes) |
| Combined head heat capacity |
840 kJ (1200 kWh) |
| Heat dissipation rate |
120W |
| Intrinsic filtration |
≥2.5 mm Al / 75 kV, < 2.7 mm Al / 75 kV |
| Collimator control |
Horizontal / vertical double leaf opening |
| Variable additional filtering |
0, 0.1mm Cu, 0.2mm Cu, 0.3mm Cu |
| DAP real-time dose display |
Displays the current dose value/rate, dose area value/rate |
| Component parameter name |
Parameter |
| Material |
Amorphous Silicon (a-Si)/Cesium Iodide (CsI) |
| FOV Size |
315.3mm × 315.3mm |
| Pixel |
154μm |
| A/D conversion |
16 bit |
| Pixel matrix |
2048 × 2048 |
| Spatial resolution |
Fluorescence Mode ≥ 2.5 LP/mm, Radiography Mode ≥ 2.8 LP/mm, Limiting Resolution 3.2 LP/mm |
| Filter grids |
Grid ratio 10:1, grid density 230 L/INCH Elastic type, can be disassembled without tools |
| Component parameter name |
Parameter |
| Touchscreen size |
15.6 inches |
| angle |
178°/178° (horizontal/vertical) |
| Resolution |
1920×1080 |
| Brightness |
500cd/m² |
| Contrast |
1200:1 |
| Tube voltage regulation range |
40kV-110kV (step 1kV) |
| Tube current regulation range |
Continuous fluoroscopy: 0.2mA - 10mA (step 0.1mA); Pulse fluoroscopy: 2mA - 13mA (step 0.1mA / 1mA); High level fluoroscopy: 2mA-18mA (step 0.1mA / 1mA); Spot Film/Photography Mode: 20mA-63mA |
| Pulse acquisition rate |
0.5/1/2/3/5/7.5/10/15 frames/sec |
| APR program fluoroscopy |
Possess, preset the fluoroscopy parameters of the abdomen, chest, feet, legs, pelvis, shoulders, skull, spine, hands, upper limbs and other parts |
| Pediatric dosing |
Possess |
| Fast switch snapshot function |
Perspective snapshot screenshot |
| Component parameter name |
Parameter |
| Pixel Depth |
16 bit |
| Hard disk storage |
Solid-state drive |
| Function |
16 levels of denoising; Last Image Hold; Continuous acquisition and playback; Realize multiple ways of image grayscale value transformation; zooming in, zooming out, and panning of images; 360-degree real-time image rotation, mirroring; Automatic window width/level adjustment, image identification; kV mA synchronous tracking; Dynamic compensation of image uniformity; medical records management; DICOM3.0 network printing; Worklist; Equipped with virtual beam limiter control and beam limiter field of view following function |
| Main Display |
27-inch 4K/8M high-definition medical display; Resolution: 3840×2160; Luminance: 800cd/m²; Contrast ratio: 1000:1; Touch function: 10-point capacitive touch; Monitor rotation angle: 270°; Vertical height range of display: 1300-2100mm; Monitor arm arc rotation radius: 1172mm; The monitor stand is equipped with built-in intelligent air pressure assistance, enabling precise hovering and quick positioning with ease |
| Component parameter name |
Parameter |
| X-ray warning lights |
Possess, the C-arm and the workstation are displayed synchronously |
| The angle at which the C-arm slides along the track arc |
155° (90°~0°~-65°) |
| Starting torque's of C-arm slides along the track |
<13 N·m |
| C-arm horizontal movement distance |
200 mm |
| C-arm vertical movement distance |
400 mm (Electric) |
| C-arm rotates around the horizontal axis |
±260° |
| C-arm swing angle horizontally |
±15° |
| The arc depth of the C-arm |
725 mm |
| The opening distance of the C arm |
985 mm |
| SID (Source-Imaging Distance) |
1195 mm |
| C-arm self-balancing function |
Possess |
| C-arm starting force when moving on a flat concrete floor |
30 N |
| Color-coded azimuth |
Possess, Ensure clear and accurate communication during the operation |
| Rack steering control handle and push handle |
Possess |
| Component parameter name |
Parameter |
| Laser positioning system |
Possess, green bidirectional high-quality laser device |
| Uninterruptible power supply system |
Possess |
| UPS built-in |
Possess |
| UPS battery level display |
Possess |
| Component parameter name |
Parameter |
| Single-phase AC power supply |
220V±10% |
| Power frequency |
50Hz±1Hz |
| Power capacity |
4.5kVA (instantaneous), 2.0kVA (continuous) |
| S/N |
Configuration name |
Unit |
Quantity |
| 1 |
Combined head (including high-voltage generator and X-ray tube) |
Set |
1 |
| 2 |
High-frequency inverters |
Set |
1 |
| 3 |
Collimator |
Set |
1 |
| 4 |
Flat detector |
Set |
1 |
| 5 |
Laser positioning system |
Set |
2 |
| 6 |
Image acquisition and processing system (including workstation configuration and software) |
Set |
1 |
| 7 |
Touch-sensitive X-ray control unit |
Set |
1 |
| 8 |
Monitor |
Set |
1 |
| 9 |
C-arm rack |
Set |
1 |
| 10 |
Uninterruptible power supply |
Set |
1 |
| 11 |
Filter grid |
Set |
1 |
| 12 |
Foot switch, cables, and connecting cables |
Set |
1 |
| 13 |
Dose-Area Product |
Set |
1 |
Configuration List (Optional)
| S/N |
Configuration name |
Unit |
| 1 |
Wireless exposure remote control |
Set |
| 2 |
Mobile trolley |
Set |
| 3 |
Long bone stitching software |
Set |
